Navistar DLB

Navistar DLB


Diamond Logic Builder™ (DLB) provides high performance diagnostics for the electrical systems on high performance International trucks and IC Buses. DLB Fleet displays vehicle signals in graphical and text format. This software also reads and displays vehicle diagnostic trouble codes as well as vehicle features and parameters.


Affirm Financing: For personal use. Terms apply.

Categories: Tags: SKU: 828005

International® Diamond Logic® Builder Fleet

Basic Functions

  • Read Fault and clear diagnostic fault codes
  • View vehicle parameters and features

Advanced Features

  • Bi-directional control of electrical components
  • View switch location and cluster configuration
  • View wiring diagrams
  • Automatic module detection
  • Graph parameters
  • Record snapshots

Compatible Vehicles

  • International® 4200/4300/4400 Series
  • International® 7000 Series
  • International® 8000 Series
  • International® CF Series (Cluster faults, Test all gauges except fuel, Odometer reset)

Recommended Hardware Specifications

  • Pentium 4 class process with a minimum 1 GHz of speed
  • 8 GB of RAM
  • 150MB of free hard disk space
  • Operating System of Windows 10 or greater
  • One or more RP1210A compatible communication devices
  • Any type of high speed Internet connection

User Permissions:
Diamond Logic Builder has different tiered permission levels allowing for more advanced use of the software.

  • Level 1 (Diagnostics) – L1 is included with active product key.
  • Level 2 (Diagnostics and Parameter Programming) – L2 access requires completion of web based training for each user.
  • Level 3 (Diagnostics, Parameter Programming and Advanced Logic) – L3 access requires completion of Instructor Led training for each user.
